G22 is an elaborated and dualified version of the G10 vari-mu compressor. It can be set to
dual-mono, but still keeps a backwards-compatibility "G10 mode" where one set of knobs
controls real stereo. To the G10 the only minor change is a re-bias of the output stage,
which allows some 4 - 5 dB more headroom while preserving the original stage's soft
transition into overload.
Some changes has been made to the sidechain functions, including a wider threshold
range and a sidechain high-pass filter. The Input and output transformers can be switched
between standard two-channel L/R mode and the M/S mode where both matrixing and
dematrixing is done internally. Linking/dynamic interaction between channels in
dual-mode can be set continuously from none to full by the Vari-link control knob, enabling
you to dial in a difference in channel processing.

Details | Technical

● Vari-Mu Compressor which can be used in Stereo-, Dual,- & MS-Mode

● transformer balanced inputs (> 10 kΩ)

● transformer balanced outputs (< 1 kΩ)

● hard relay bypass

● 230V mains voltage (others on request)

Details | Operability

● classic compressor parameters: Input-/Output-Gain, Threshold, Ratio, Attack,

Release & Bypass

● wide range of operation levels allows clean and colored behavior

● selectable Low Cut (80 Hz/octave) & Hard Bypass
