This final mixdown feature transposes the positions of the DAW faders, onto the analogue layer of the console, giving post-processing, flying-fader style analogue automation controlled from the DAW.
General Specification
- Two inputs per channel – seamlessly switch from mix to record inputs at the push of a button
- Third channel strip Input for dual-layer use
- Mix up to 48 Mono Signals at once
- Marinair® Transformers on Mix, AFL, CUE bus for true Neve® voltage mixing
- 80 - series Neve sound in a compact frame
- Large format console centre section. Multiple speaker sets, dual cue system and three-way talkback system
- Internal snapshot system to save/load multiple all console settings across multiple sessions
- 500 series slots for internal expansion options
- 1073 preamps and DI inputs with Smart Routing for recording in the live or control room
- In-line console capability
- 25-way D-Type and balanced jack inputs on rear and on the front for a combination of simple and professional I/O connection
- Heat Dissipation: 225 watts
- Power factor: >0.87
- Input voltage range: 90-240v AC Only
- Current: Amps RMS 240v1.1A
- Current: Amps RMS 90v2.3A
- Current: Switch-On surge current -4 amps for 7ms (average)
Audio Performance
Line Input B to Direct Output
- Headroom+27.7dBu @ 1kHz (<0.5% THD+N)
- Frequency response typically +/-0.1dBu, 20Hz to 20kHz
- Distortion (THD+N)Typically 0.004% @ 1kHz (measured at +10dBu 10Hz to 80kHz filter)
- Noise <-88dBu (20Hz to 22kHz filter)
Line B to Mix Output
- Headroom+27.4dBu @ 1kHz (<0.5% THD+N)
- Frequency ResponseTypically +/-0.1dBu, 20Hz to 20kHz
- Distortion (THD+N)Typically 0.004% @ 1kHz (measured at +10dBu, 10Hz to 80kHz filter)
- Noise<-85dBu (20Hz to 20kHz filter, no channel routed)<-84dBu (20Hz to 22kHz filter, 1 channel routed)<-80dBu (20Hz to 22kHz filter, 24channels routed)
1073 Input to 1073 Output
- Headroom+28.8dBu @ 1kHz (<0.5% THD+N)
- Frequency Response Typically +/-0.1dB, 20Hz to 20kHz
- Distortion (THD+N)Typically 0.005% @ 1kHz (measured at +20dBu, 10Hz to 80kHz filter)
- Noise(EIN)<-125.5dBu (20Hz to 22kHz filter, 60dB gain, input terminated 150Ω R)
Dimensions
- HeightTo top of LS Shelf (No Stand): 500mm (19.68 inches)
- Height To Top of LS Shelf (With Stand): 990mm (38.98 inches)
- Width: 1190mm (46.85 inches)
- Depth: 850mm (33.46inches)
- Weight(no stand): 53kg (117 pounds)
- Weight (with stand): 64kg (141 pounds)
- Console Weight: (with packaging) 84kg (185 pounds)
- Stand Weight: (with packaging) 12kg (26 pounds)
